Description
Our Rotary Converters are meant for military as well as commercial applications. We manufacture AC-AC, AC-DC and DC-AC rotary converters of various ratings, rotational speeds and frequency conversion ratios.Our Naval product range is type certified to MIL standards for EMI/EMC as well as to the stringent environmental standards for defense services (JSS 55555). Our Rotary Converters are operated through our micro-processor based control panels in order to provide the best performance and protection to the user. Our Rotary Converters are “monoblock”, with no external rotating interfaces.
General Specifications
| Rotary Frequency Converters up to 1000KVA: |
| AC to AC |
50Hz to 60/ 100/ 150/ 200/ 400Hz or vice versa or custom.Standard or Non-standard Voltages up to 1,000VAC available. |
| DC to AC |
DCto50/ 60/ 100/ 150 / 200/ 400/ 500Hz or custom.Standard or Non-standard Voltages up to 1,000VAC available. |
| AC to DC |
Standard or Non-standard Voltages. |
| Speed |
600/1000 / 1200 / 1500/1800/2000/2400/3000RPM or as necessitated by conversion ratio. |
| Class of Insulation |
Class F/H. |
| Specifications |
EED-S-806(R1), IS-325, IS-4722, NES-627, NES-629, EED-Q-267(R2), IS-13364(Part2), IS-10242, IEC–34, BS-5000(Part99) and EED-Q-242(R2). |
